Couplers
ELECTRICAL SPECIFICATIONS
Type: 2-Way / 3-Way / 4-Way
Model No.: STPS-0825021 / STPS-0825031 / STPS-0825041
Freq. Band (MHz): 800-2500 / 800-2500 / 800-2500
Attenuation (dB): 3.0±0.5 / 4.8±0.5 / 6.0±0.8
VSWR: ≤1.3 / ≤1.3 / ≤1.3
Impedance (Ω): 50 / 50 / 50
Input Power (W): 100 / 100 / 100
Connector: N-female / N-female / N-female
DC Passage: DC transmission between all terminations
MACHANICAL SPECIFICATIONS
Weight (Kg): 0.40 / 0.40 / 0.40
Dimension (LxWxH) mm: 205x45x25 / 205x65x25 / 205x65x45
MATERIAL & PLATING
Body: Aluminium Powder Coated
Connector Body: Brass Nickel Plated
Mounting: Ceiling Mountable
